File:1783 balloonj.jpg

Summary

1786 description of the historic Montgolfier Brothers' 1783 balloon flight. Illustration with engineering proportions and description. Translation: Figure and exact proportions of the "Aerostatic Globe", which was the first to first carry men through the air.

Engineering data is provided in prerevolutionary French units:

Height of the Globe: 70 pieds Weight of the Globe: 1600 Livres Diameter: 46 pied Lifting capacity: between 1600 and 1700 livres Volume: 60000 pieds cubes Gallery: 3 pieds wide These units, while translating literally to "feet" and "pounds", varied regionally and the version was not specified by the engraver. If Parisian units were used (by far the most likely) then this translates to metric and Imperial measurements as follows:

Height of the globe: 70 pieds du roi = 22.7 metres = about 75 ft Weight of the globe: 1600 Livres = 780 kg = 1700 lb Diameter: 46 pieds du roi = 14.9m = 49 ft Lifting capacity: 1600-1700 livre = About 780-830 kg = about 1700-1800 lb. Volume: 60000 pieds cubes = ~2000 cubic metres or 2,000,000 Litres = 73000 cubic ft. Gallery: 3 pied du roi = 1 metre= 3 ft Remainder of translation:

The top portion was surrounded by fleurs-de-lys, with the twelve zodiac signs below. In the middle portion were images of the king's face, each surrounded by a sun. The bottom section was filled with mascarons and garlands; Several eagle's wings appear to support this powerful machine in the air. All of this ornamentation was gold on a beautiful blue background, so that that this superb globe appeared to be gold and azure. The circular gallery, in which we see the Marquis D'Arlandes and Mr. Pilatre de Rozier, was covered in crimson draperies with gold fringes. Français : Description de 1786 du vol en ballon historique des frères Montgolfier en 1783, avec proportions et description d'ingénierie. Türkçe: Montgolfier Kardeşler'in tarihi balonunun mühendislik bilgilerini de içeren 1786 tarihli bir şeması. Date 1786 Source This image is available from the United States Library of Congress's Prints and Photographs division under the digital ID ppmsca.02447. This tag does not indicate the copyright status of the attached work. A normal copyright tag is still required. See Commons:Licensing. العربية ∙ беларуская (тарашкевіца) ∙ বাংলা ∙ čeština ∙ Deutsch ∙ English ∙ español ∙ فارسی ∙ suomi ∙ français ∙ galego ∙ עברית ∙ magyar ∙ Bahasa Indonesia ∙ italiano ∙ 日本語 ∙ lietuvių ∙ македонски ∙ മലയാളം ∙ Nederlands ∙ polski ∙ português ∙ português do Brasil ∙ română ∙ русский ∙ sicilianu ∙ slovenčina ∙ slovenščina ∙ Türkçe ∙ українська ∙ 简体中文 ∙ 繁體中文 ∙ +/−

Author Unknown author Other versions Restored version of Image:1783 balloon.jpg with dirt and water damage corrected, creases and imprints removed, levels and color balance adjusted, and various local fixes to brightness and contrast. Many lines redrawn.
