PG Arrangement. 1 – 3”/50 Rapid Fire (RF) single gun. 2 – 40mm Mk 3 Mod 4 single gun. 3 – twin AN/M2 .50 Browning machine guns (port/starboard). 4 – Gun director. 5 – Bridge. 6 – LM1500 gas turbine engine for high-speed. 7 – V12 diesel engines for economical cruising (port/starboard). (Drawing: Patrol Gunboat Reunion Association)
