Summary
Coefficients of drag and lift versus angle of attack. Stall speed corresponds to the angle of attack at the maximum coefficient of lift U.S. Dept. of Transportation, FAA - Pilot's Handbook of Aeronautical Knowledge, FFA-H-8083-25B, https://www.faa.gov/regulations_policies/handbooks_manuals/aviation/phak/ Stall speed corresponds to the Angle of Attack at the Maximum Coefficient of Lift
