File:Jet engine.svg

File
File history
File usage
Metadata

Size of this PNG preview of this SVG file: 800 × 320 pixels. Other resolution: 2,560 × 1,024 pixels.

Original file ‎(SVG file, nominally 1,280 × 512 pixels, file size: 499 KB)

Summary

File information
Description	English: Diagram of a typical gas turbine jet engine (in English). Air is compressed by the fan blades as it enters the engine, and it is mixed and burned with fuel in the combustion section. The hot exhaust gases provide forward thrust and turn the turbines which drive the compressor fan blades. Template:De Template:Fr Chinese: 一个典型的燃气涡轮喷气发动机图解。 Template:Ru
Source	Own work, vector version of en:Image:FAA-8083-3A Fig 14-1.PNG which comes from an FAA handbook
