Summary
NAA's final WS-110A proposal, built as the XB-70 NASA - NASA CR-115703, Volume 2, page 23. Transferred from en.wikipedia to Commons by TheDJ using CommonsHelper. NAA's final proposal for WS-110A, which would become the B-70. "BLC" refers to "boundary layer control", suction used to smooth the airflow in the engine intakes.
