Summary
Looking towards a load through a length l of lossless transmission line, the impedance changes as l increases, following the blue circle. (This impedance is characterized by its reflection coefficient Vreflected / Vincident.) The blue circle, centered within the Smith chart, is sometimes called an SWR circle (short for constant standing wave ratio). Date 24 July 2012 Source Own work Author Sbyrnes321 Uses File:Smith_chart_gen.svg by Wdwd. Made in Inkscape.
