Summary
NAA's original proposal for WS-110A. The "floating panels" are large fuel tanks the size of a B-47.[8] Boeing's design was almost identical, differing largely in having a single vertical stabilizer and having two of its engines in pods at the outer edges of the inner wing section. North American Aircraft - NASA CR-115703, Volume 2, page 22. North American Aircraft's original proposal for WS-110A, which would eventually lead to the B-70. From NASA CR-115703, Volume 2, page 22.
