{{Location map+}} places one or more location marks on a map, with optional labels. It is in the same family of templates as the Location map template and the documentation for that template might be helpful.

Template:Location map+ uses a helper template, {{Location map~}}, one or more times to generate a mark for each location.

Usage

Main template (one per map) Helper template (one per location to be marked)
Multi-line style
{{Location map+
| {{{1}}}
| width          =
| float          =
| border         =
| caption        =
| alt            =
| maplink        =
| relief         =
| AlternativeMap =
| overlay_image  =
| places         =
}}
{{Location map~
| {{{1}}}
| label       =
| label_size  =
| label_width =
| position    =
| background  =
| mark        =
| marksize    =
| link        =
| lat_deg     =
| lon_deg     =
}}
{{Location map~
| {{{1}}}
| label       =
| label_size  =
| label_width =
| position    =
| background  =
| mark        =
| marksize    =
| link        =
| lat_deg     =
| lat_min     =
| lat_sec     =
| lat_dir     =
| lon_deg     =
| lon_min     =
| lon_sec     =
| lon_dir     =
}}
{{Location map~
| {{{1}}}
| label       =
| label_size  =
| label_width =
| position    =
| background  =
| mark        =
| marksize    =
| link        =
| coordinates =
}}
Single-line style
{{Location map~ |{{{1}}} |label_size= |label_width= |background= |marksize= |mark= |lat_deg= |lon_deg= |position= |label= |link=}}
{{Location map~ |{{{1}}} |label_size= |label_width= |background= |marksize= |mark=  |lat_deg= |lat_min= |lat_sec= |lat_dir= |lon_deg= |lon_min= |lon_sec= |lon_dir= |position= |label= |link=}}
{{Location map~ |{{{1}}} |label_size= |label_width= |background= |marksize= |mark= |coordinates= |position= |label= |link=}}

Note: in single-line style, parameters order is chosen so that it's easier to maintain vertical alignment in subsequent {{Location map~{{---}}{{---}}{{---}}{{---}}{{---}}{{---}}{{---}}{{---}}{{---}}{{---}}{{---}}{{---}}{{---}}{{---}}{{---}}{{---}}{{---}}{{---}}{{---}}{{---}}}} calls (which improves wikicode readability). Parameters that are rarely given values, or those whose values (usually) have constant or only slightly varying lengths (in characters), are placed first; parameters whose values frequently have very different lengths are placed last. See an example below (note the alignment of |marksize= and |position= parameters in the wiki mark-up).

Parameters

Parameters for Location map+
Parameter Description
{{{1}}} Required. Use the name of the map as the first unnamed parameter. For example, specifying England will use the values for England in Module:Location map/data/England if it exists, or {{Location map England}} otherwise. See the examples below or all subpages.
width Determines the width of the map in pixels, overriding any default values. Do not include px: for example, use width=300, not width=300px.
default_width Determines the default width of the map in pixels, intended for use by templates e.g. place infoboxes. The default value is 240. Do not include px. This value will be multiplied by the defaultscale parameter specified in individual map templates, if it exists, in order to achieve an appropriate size for vertical maps. For example, if default_width=200 is given, a map of Thailand will be displayed with a width of 200×0.57 = 114 pixels (as specified in Module:Location map/data/Thailand).
float Specifies the position of the map on the page. Valid values are left, right, center and none. The default is right.
border Specifies the color of the 1px map border. The default is lightgrey (see web colors). If set to none, no border will be generated. This parameter is seldom used.
caption The text of a caption to be displayed below the map. Specifying a caption will cause the map to be displayed with a frame. If caption is defined but is not assigned a value, the map will not be framed and no caption will be displayed. If caption is not defined, the map will not be framed and a default caption will be generated. The default caption is created from the label parameter (or the current page name if label not defined) and the name parameter from map definition template. See the examples below.
alt Alt text for map; used by screen readers, see WP:ALT.
maplink Specifies a wiki link that will be followed when clicking the map, by default to the map source file. Can be deactivated with maplink =, which can be useful to avoid mis-clicks if there are links associated with markers and labels.
relief Any non-blank value (1, yes, etc.) will cause the template to display the map specified in the map definition template as image1, which is usually a relief map. See the example at Location map+/relief. Other numerical values such as 2 or 3 will display image2 or image3, if those images are defined.
AlternativeMap Allows the use of an alternative map. The image must have the same edge coordinates as the location map template. See the example at Location map+/AlternativeMap.
overlay_image Allows an overlay to be superimposed on the map. This parameter is seldom used. See the example at Location map+/overlay.
places Specifies one or more place markers using {{Location map~}}.
Parameters for Location map~
Parameter Description
{{{1}}} Required. Use the name of the map as the first unnamed parameter. For example, specifying England will use the values for England in Module:Location map/data/England if it exists, or {{Location map England}} otherwise. See the examples below.
Label
label The text of the label to display next to the mark. A wiki link can be used. The default if not specified is no label, just the marker. Do not use ‎<div>...‎</div> tags to attempt to position the label; use |label_size= and |position= instead.
label_size The font size to use for the label, given as a percentage of the label's (already reduced) normal font size (<100 = smaller, >100 = larger). The default is 91; obey MOS:FONTSIZE if setting to a lower value. Do not include %: for example, use label_size=95, not label_size=95%. If set to 0, the label is displayed only when the user hovers over the mark.
label_width The width to use for the label, given as an em size; the default width is 6. Do not include em: for example, use |label_width=7, not |label_width=7em.
position The position of the label relative to the mark. Valid values are left, right, top and bottom. The default is right.
background The background color to use for the label. See Web colors. The default is no background color, which shows the map image behind the label.
Mark
mark The name of an image to display as the mark. The default is Red pog.svg (Red pog.svg). More mark images are available, in particular, at Commons:Location markers and Commons:Category:Map icons.
marksize The size of the mark in pixels. The default is 8. Do not include px: for example, use marksize=10, not marksize=10px.
link Specifies a wiki link which will be followed if the reader clicks on the mark. Do not include [[]]: for example, use link=Yellowstone National Park, not link=[[Yellowstone National Park]].
Coordinates
lat_deg Usual Required. The degrees of latitude, using decimal degrees. Logically, use negative number for southern latitude.
lon_deg Required. The degrees of longitude, using decimal degrees. Logically, use negative number for western longitude.
lat_deg Detailed Required. The degrees of latitude. The minutes and, probably, the seconds must be specified.[Note 1]
lat_min The minutes of latitude.[Note 1] The sign should match that of lat_deg.
lat_sec The seconds of latitude. Usually not necessary.[Note 1] The sign should match that of lat_deg.
lat_dir N if north (default value) or S for south of the Equator. Other values will be disregarded.
lon_deg Required. The degrees of longitude. The minutes and, probably, the seconds must be specified.[Note 1]
lon_min The minutes of longitude.[Note 1] The sign should match that of lon_deg.
lon_sec The seconds of longitude. Usually not necessary.[Note 1] The sign should match that of lon_deg.
lon_dir E for east (default value) or W for west of the Prime Meridian. Other values will be disregarded.
cooordinates Alternative The coordinates using {{Coord}} template, e.g. {{coord|48.067|-2.863}}.

Notes:

  1. 1.0 1.1 1.2 1.3 1.4 1.5 Appropriate precision should be used. For example, the whole US map, with a 1000‑pixel width, has a resolution of about 5 km/pixel. Only 2 decimal places of precision in decimal degrees format (≈1 km), or whole minutes (≈1.7 km) in DMS format, are required.

Available maps

Location maps can be found using these sources:

Special:PrefixIndex/Module:Location map/data/ - checked before a map template is searched for. New maps should be created here rather than creating new templates.
List of templates - 1050 templates were available when the list was generated.
Category:Location map modules - templates sorted by category.
Special:WhatLinksHere/Template:Location map/Info - a search that might help.
Special:Prefixindex/Template:Location map - another search that might help.

Examples

This example does not designate the caption parameter. It demonstrates the use of the defaults. Notice that the default caption is the page name followed by the map name in parenthesis and that the label position is automatically adjusted if it is too close to an edge.

Lua error in Module:Location_map/multi at line 27: Unable to find the specified location map definition: "Module:Location map/data/Australia" does not exist.

{{Location map+ | Australia
| places =
  {{Location map~ | Australia
    | label = Sydney
    | lat_deg = -33.86
    | lon_deg = 151.21 }}
  {{Location map~ | Australia
    | label = Melbourne
    | coordinates = {{coord|-37.81|144.96}}
  }}
}}
}}

This example uses a designated but empty caption. It demonstrates coordinates using decimal degrees, a 10px mark with a link, and {{Location map~}} entries listed in single-line style.

Lua error in Module:Location_map/multi at line 27: Unable to find the specified location map definition: "Module:Location map/data/France" does not exist.

{{Location map+ | France
| caption =
| places =
  {{Location map~ |France |marksize=10 |lat_deg=48.8567 |lon_deg=2.3508 |position=top    |label=Paris     |link=Paris    }}
  {{Location map~ |France |marksize= 9 |lat_deg=43.2964 |lon_deg=5.3610 |position=bottom |label=Marseille |link=Marseille}}
}}

This example uses caption with an assigned value. It demonstrates coordinates in degree, minute, second format, a relief map, label background color and linked labels.

{{Location map+ | USA
| width = 300
| caption = Some cites in the United States
| relief = 1
| places =
  {{Location map~ | USA
    | label = [[New York City|New York]]
    | position =
    | background = white
    | mark = Cyan pog.svg
    | alt = alt text for New York City
    | link = New York City
    | lat_deg = 40 | lat_min = 43 | lat_dir = N
    | lon_deg = 74 | lon_min = 0  | lon_dir = W
  }}
  {{Location map~| USA
    | label = [[San Francisco]]
    | position =
    | background = white
    | mark = Purple pog.svg
    | alt = alt text for San Francisco
    | link = San Francisco
    | lat_deg = 37  | lat_min = 46 | lat_dir = N
    | lon_deg = 122 | lon_min = 25 | lon_dir = W
  }}
}}

Also see the examples for {{Location map}} and {{Location map many}}, as well as:

Template data

TemplateData documentation used by VisualEditor and other tools
Click here to see a monthly parameter usage report for this template in articles based on this TemplateData.

TemplateData for Location map~

This template places one or more location marks on a map.

Template parameters

ParameterDescriptionTypeStatus
Map name1

The name of the map to be used

Stringrequired
Map widthwidth

Determines the width of the map in pixels, overriding any default values. Do not include "px", for example: "300", not "300px".

Numberoptional
Default widthdefault_width

Determines the default width of the map in pixels, intended for use by templates such as infoboxes. The default value is 240. Do not include "px". This value will be multiplied by the defaultscale parameter specified in individual map templates, if it exists, in order to achieve an appropriate size for vertical maps.

Numberoptional
Positionfloat

Specifies the position of the map on the page. Valid values are left, right, center and none. The default is right.

Stringoptional
Border colorborder

Specifies the color of the map border. If set to none, no border will be generated.

Stringoptional
Map captioncaption

The text of a caption to be displayed below the map. If caption is defined but is not assigned a value, the map will not be framed and no caption will be displayed. If caption is not defined, the map will not be framed and a default caption will be generated.

Stringoptional
Alt textalt

Alt text for map; used by screen readers.

Stringoptional
Alternative map from templaterelief

Any non-blank value (1, yes, etc.) will cause the template to display the map specified in the map definition template as image1, which is usually a relief map. If more than one relief map is defined, "2" will display "image2", and so on.

Stringoptional
Alternative map not from templateAlternativeMap

Allows the use of an alternative map. The image must have the same edge coordinates as the map template.

Stringoptional
Overlay imageoverlay_image

Allows an overlay to be superimposed on the map. This parameter is seldom used.

Stringoptional
Place markersplaces

Specifies one or more place markers using Location map~.

Stringrequired

See also

  • OODA WIKI:Maps for OODA WIKI - A list of mapping tools available on OODA WIKI
  • {{Location map}} - For displaying one mark using latitude and longitude.
  • {{Location map many}} - For displaying multiple marks using latitude and longitude.
  • Commons:Category:Map pointers - List of the many Wikimedia Commons pointer symbols.
  • {{OSM Location map}} - OpenStreetMap map with an "interactive fullscreen" version. Allows for labels, numbered dots, a heading, caption, mini-locator map and overlays.
  • {{Overlay}} - Allows image numbered, textual number, or color tag overlays to be positioned over an image to indicate particular features in the image.
  • {{CSS crop}} - Wrapper template that allows cropping the map.
